NTO light module you love and your customer loves.
NTO LED light modules are idea choice for cabinet lighting, kitchen lighting, display shelf lighting, step lighting and interior lighting design etc.
1. Only 5mm thickness slim design, easy integrate into your customer’s cabinet;
2. High CRI and no glare flat lighting, Maximize the realization of better lighting environmental atmosphere;
3. Easy installing, fast connection, really the way of PNP( plug and play);
4. Looks like OLED lighting module, much cheaper, more reliable than OLED. Several utility model patents pending.
For the standard series products we have released 5 types NTO light module products including Square shape, Rectangle shape, Triangle shape and Quarter Annulus (Ring) shape.
90 NTO mini LED panel light moudule dimension" width="900" height="316" srcset="http://www.notoled.com/wp-content/uploads/2014/05/Standard-Series-NTO-mini-LED-panel-light-moudule-dimension.jpg 1291w" sizes="(max-width: 900px) 100vw, 900px"/>
NTO Light Module Family
NTO lighting module application gallery
CONTACT NOW!
Contact for more details and quotation!
NTO module idea source
Our idea source of NTO LED light module is OLED(Organic Light-Emitting Diode) lighting
module.
OLED lighting have advantage of very thin and flat, low glare, low power consumption. Many people take it as the next generation lighting.
But at present the OLED lighting have big problem on the very high price and special OLED driving method.
We want to design a product who can take the advantage of OLED lighting but much cheaper and reliable.
OLED lighting have advantage of very thin and flat, low glare, low power consumption. Many people take it as the next generation lighting.
But at present the OLED lighting have big problem on the very high price and special OLED driving method.
We want to design a product who can take the advantage of OLED lighting but much cheaper and reliable.
Concept design and development
We apply the LED+LGP(Light Guide Plate) design who is also applied for the latest BLU(Back Light Unit) of LCD
display and LED TV.
After a lot of testing and comparison, we decide to apply 2mm Laser-Engraving LGP because its engraved 3D concave dots on the surface have excellent light guiding performance together with a patent micro-structure diffuser plate.
To make sure people could power the NTO panel module very easy; we design it to be popular 12V DC input, 2meters long two leads cable with reliabel plug connector.
After a lot of testing and comparison, we decide to apply 2mm Laser-Engraving LGP because its engraved 3D concave dots on the surface have excellent light guiding performance together with a patent micro-structure diffuser plate.
To make sure people could power the NTO panel module very easy; we design it to be popular 12V DC input, 2meters long two leads cable with reliabel plug connector.
NTO light module family
5 different types of NTO LED panel modules were designed to meet the demands of furniture lighting, Kitchen lighting, cabinet lighting, display shelf lighting and creative lighting design etc.
They are 100x100mm Square panel module; 200x100mm Rectangle panel module; 300x100mm Rectangle panel module; 100mm side Equilateral Triangle panel module; and 100mm side Quarter Annulus panel module
Now all the 5 types were released.
They are 100x100mm Square panel module; 200x100mm Rectangle panel module; 300x100mm Rectangle panel module; 100mm side Equilateral Triangle panel module; and 100mm side Quarter Annulus panel module
Now all the 5 types were released.
